FEATURES:

• Capacity: 18 m3/ hr
• Easy mobility
• No heavy foundation required. Only PCC work required
• Inbuilt cement feeding hopper on plant chassis
• Cement screw conveyor & electric vibrators for sand & cement
• USB based removable storage is possible which eliminates the need of SCADA
• PLC & HMI touch screen for better accuracy & consistency
• Control panel housed in a separate steel cabinet

SPECIFICATIONS:

• Output: 18 Cum/hr
• Mixer Type: Turbo Pan
• Output per Batch: 0.75 m3
• Nos. of Bins: 3/4
• Storage Capacity (Each Bin): 3.5 m3
• Aggregate Charging Conveyor: Yes
• Cement Hopper: Inbuilt
• Screw Conveyor for Cement: Yes
• Water Tank: Inbuilt
• Water Pump: 2 Nos.
• Additive Tank: Inbuilt
• Additive Pump: 1 No.
• Control Panel: Fully Automatic
• Mobility: Provided - 4W
• Load Out Conveyor: Optional
• Total connected Power- 51.35 HP (Without Load-out conveyor)

DESCRIPTIONS:

• A Turbo Pan Mixer mounted on a steel frame, made from heavy duty structural steel. The mixer in mounted on 4 load cells and driven by a planetary gearbox with adequate drive. The Mixer is lined with wear plate from bottom & side.
• The mixer gate is hydraulic operated.
• A sturdy design chassis made from heavy duty structural steel.
• 2 Nos. of Aggregate Silo of 3.5 m3 capacity each with dozing belt conveyor of adequate drive unit below each silo to feed the Mixer.
• A Cement Hopper of 1 m3 capacity with screw conveyor with adequate drive unit.
• A water Tank of 400 lit. capacity with a submersible pump for feeding water into the Mixer. A water level sensor is fitted for automatic refilling of water.
• A separate electronic water flow meter for addition of water in mixer indicating weight in kg.
• A separate water pump for feeding water in to water tank is provided.
• Two axles for mobility - one rear axle (fixed) with 2 Nos. of tyre, tube, wheel plate & another one is steering front axle (toeing) with 2 Nos. of tyre, tube, wheel plate.
• An Additive Tank of 100 lit. capacity with a self priming pump.
• A single integrated power & control panel with digital display.
• Inbuilt serial Printer interface. (Printer in Customer Scope)
• Powerful recipe management for 99 concrete mix designs.
• Total connected Power- 51.35 HP (Without Load-out conveyor)
