• Frequency: 50Hz(60Hz)
• Power: 1HP
• Power: 0.75kW
• Phase: 1
• Voltage: 200-240V
• Poles: 2
• Discharge Diameter: 2inch
• Discharge Diameter: 50mm
• Max Head: 16M
• Max Flow: 0.35m3/min
• Solid Passage: Ф6mm
• Wt.: 21KG
• Height: 460mm
• Pump Dia.: 255mm

FEATURES:

• Motor: Quality motor with a level of protection IP68, suitable for continuous duty.
• Thermal Protector: Single phase model with built-in thermal protector prevents any burning damage to the motor.
• Motor Casing: Stainless steel casing greatly reduces the pump’s weight and easy to carry for the work.
• Pump Casing: Tough cast iron casing guarantees longer servicing life.
• Impeller: Excellent durability, semi-open type impeller design, prevents clogging by mud, sand, etc.
• Suction Cover: Easily replaceable.
• Strainer: Material of Engineering Plastic of 1/3 and 1/2HP models, and Stainless Steel for 1~3HP models.
• Triplex Seals: Equipped with a double mechanical seal with one oil seal.
• The better pumping performance results in less electricity consumption, large water volume, convenient usage, and maintenance.

APPLICATIONS:

• Very good for pumps with clean non-volatile liquids without solids or fibers in below applications as : Civil engineering & construction, Fountains and water features, Tunnel & caisson drainage, Agricultural irrigation, Drainage of seepage water, rain wastewater, bathing and swimming pools, industrial applications.
