- Frequency: 50Hz
- Power: 1HP
- Power: 0.75kW
- Phase: 1
- Voltage: 200-240V
- Poles: 2
- Discharge Diameter: 2inch
- Discharge Diameter: 50mm
- Max Head: 12M
- Max Flow: 0.5m3/min
- Solid Passage: Ф25mm
- Wt.: 22KG
- Height: 470mm
- Pump Dia.: 290mm
FEATURES:
- Non-Clog Impeller : Hydro dynamically well-balanced single blade semi-open non-clogging type for sewage application.
- Advanced Shredder Mechanism : Surface hardening heat treatment is done on impeller vanes and cutting edges, both of which are the main components of the shredder mechanism.
- Epoxy Cable Sealing Base Unique “Epoxy Cable Sealing Base” to ensure 100% capability to block the water vapor into the motor from outside.
- Triplex Seal System : Oil-bathed double mechanical seals (Silicon-Carbide/Silicon-Carbide) and separate oil seal ensure a longer pump life.
- IP68 Motor: Electricity-saving Motor with a level of IP68, suitable for continuous duty. Digitalized balanced motor shaft and rotor.
- Quiet : The well-balanced motor shaft and impeller enables the pump to run evenly with less noise.
- Compact and Light-Weight : Designed to be light, so easy to carry and handle.
- Economical : Long-runnable with less maintenance cost.
APPLICATIONS:
Ideal for sewage, industrial & groundwater drainage installation in the following fields:
- Wastewater Treatment Plants
- Sewage pumping stations
- Sewage treatment plants
- Septic tanks
- Collecting and settling sumps
- Industrial Sites
- Mills and factories for pumping dirty water
- Water purification plants
- Flood and emergency
- Residential Sites
- Residential houses
- Flats and apartments
- Commercial Sites
- Restaurants and shops
- Markets and supermarkets
- Hospitals, stations, and theaters
- Garages and laundries.
