• Input Voltage:  220V/ 110V
• Working Voltage:  DC 24V
• Ambient Temperature:  -50 ~ +50 Celsius degree
• Gate Width (per wing):  <= 6M
• Gate Weight (per wing):  <= 600kgs
• Regular Components:  2 motors, 1 panel, 2 remote controllers
• Optional Parts:  IR sensor, storage battery, visual doorbell, card reader, fingerprint reader
• Weight (kg):  23
• Dimension (cm):  42*32*31
• Package:  Color printing carton with foam
• Warranty validity of 1 year after installation

Features:

1. Easier to drive the gate: The motor is mounted on the far end from the hinge point.
2. Special sliding groove: This enables the tolerance to the unevenness of road surface up to 90mm, maximum tolerance up to 300mm.
3. Unlimited opening angle: As far as the opener is concerned, the opening angle can be greater than 180°.
4. Automatic locking unit: This unit combines the closing and the locking actions.
5. Optional manual operation: At power cut, the operation mode can be easily switched to manual with a key.
6. Convenient installation: Can be mounted to any gate regardless of the condition of gate posts or gate itself.

Functions:

1. Single or dual gate arm close or open operation mode: Users can make their choice with the remote controller.
2. Prevent mal-operation: The opener can distinguish any overlapped instruction.
3. Reminding the close-up: At fully closing and locking of the gate, the controller will remind the user by giving a warning tone of "Di".
4. Optional infra-red protection: When linked with infrared detector, the opener can pause operation whenever any passenger or vehicle is in between the gate.
5. Compatible with auto-identification system: Linked with camera, card reader, etc., the opener can jointly achieve the purpose of safety and antitheft, entry or exit.
6. Lock-up of control box: Use the remote controller to deactivate the panel buttons to prevent unauthorized operation of the gate.
7. Anti-Entrapment protection: The opener will automatically stop running in the case.
8. Overtime protection: To protect the motors, a one-way operation will be automatically terminated at the 60th second.
9. Automatic closing (optional function): The user can choose to activate this function by pre-setting in the control box.
10. Compatible with stand-by power supply: The opener can work with stand-by power supply, such as storage battery or solar energy battery.
